📋 Total Parameter
Parameters of other Surface Mounted Removable Bollard
| Diameter |
Height |
Wall Thickness |
Material |
Lock |
Type |
Finish |
| 89mm |
960mm |
3mm |
Carbon steel / 304SS / 316SS |
Keylock |
Rotate |
Carbon steel: E-coated and powder coated Stainless steel: Satin polish |
| 89mm |
1140mm |
3mm |
Carbon steel / 304SS / 316SS |
Keylock |
Rotate |
| 140mm |
960mm |
3mm |
Carbon steel / 304SS / 316SS |
Keylock |
Rotate |
| 140mm |
1140mm |
3mm |
Carbon steel / 304SS / 316SS |
Keylock |
Rotate |
| 89mm |
960mm |
3mm |
Carbon steel / 304SS / 316SS |
Pad / Keylock |
Slide |
| 89mm |
1140mm |
3mm |
Carbon steel / 304SS / 316SS |
Pad / Keylock |
Slide |
| 140mm |
960mm |
3mm |
Carbon steel / 304SS / 316SS |
Pad / Keylock |
Slide |
| 140mm |
1140mm |
3mm |
Carbon steel / 304SS / 319SS |
Pad / Keylock |
Slide |
ⓘ Remarks: Carbon steel is defaulted to Q235 Steel. For finish, for carbon steel, it is defaulted to hot-dip galvanizing or E-coated + powder coating; for stainless steel, it is defaulted to satin polishing.
❓ Frequently Asked Questions
QWhat is the model number of this surface mounted removable bollard?
The model number is KVS-REB(IP)-89.965.3-0. It features a 89mm diameter, 965mm height, and 3mm wall thickness, made from Q235 steel with an embedded part size of L100×W100×H225×T4.
QWhat materials are available for the removable bollard?
The bollard is available in Carbon Steel (Q235), 304 Stainless Steel, and 316 Stainless Steel. Each material option is suited to different environmental and aesthetic requirements.
QWhat finish options are available for the bollard?
For carbon steel bollards, the standard finish is hot-dip galvanizing or E-coated plus powder coating. For stainless steel bollards, the default finish is satin polishing, providing a clean and durable surface appearance.
QWhat lock types are available for this bollard?
Two lock types are available: Keylock and Pad/Keylock. These options provide flexible security solutions depending on the application and access control requirements.
QWhat are the available removal types for this bollard?
The bollard is available in two removal types: Rotate and Slide. The rotate type requires the bollard to be turned to unlock and remove, while the slide type allows it to be pulled straight out after unlocking.
QWhat size options are available for the surface mounted removable bollard?
The bollard is available in two diameter options — 89mm and 140mm — and two height options — 960mm and 1140mm. All variants feature a standard wall thickness of 3mm, offering versatile configurations for different site needs.
