KAVASS
1 / 4
| Model | Material | Diameter (mm) | Height (mm) | Thickness (mm) | Size of Base Plate |
|---|---|---|---|---|---|
| KVS-FFB-89.900.3-0EP | Q235 Steel | 89 | 900 | 3 | ∅210*T10 |
| KVS-FFB-140.1200.3-0EP | Q235 Steel | 140 | 1200 | 3 | ∅260*T10 |
| Diameter | Height | Wall Thickness | Base Plate Size | Mounting Hole | Material | Head | Finish |
|---|---|---|---|---|---|---|---|
| 89mm | 900mm | 3mm | Φ170*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel |
Carbon steel: Hot dip galvanized/E-coated and powder coated Stainless steel: Satin polish |
| 89mm | 1200mm | 3mm | Φ170*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 114mm | 900mm | 3mm | Φ200*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 114mm | 1200mm | 3mm | Φ200*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 140mm | 900mm | 3mm | Φ220*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 140mm | 1200mm | 3mm | Φ220*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 140mm | 900mm | 5mm | Φ220*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 140mm | 1200mm | 5mm | Φ220*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 165mm | 900mm | 3mm | Φ250*8mm | 4*Φ16mm | Carbon steel | Flat/Dome/Bevel | |
| 165mm | 1200mm | 3mm | Φ250*8mm | 4*Φ16mm | Carbon steel | Flat/Dome/Bevel | |
| 165mm | 900mm | 5mm | Φ250*8mm | 4*Φ16mm | Carbon steel | Flat/Dome/Bevel | |
| 165mm | 1200mm | 5mm | Φ250*8mm | 4*Φ16mm | Carbon steel | Flat/Dome/Bevel | |
| 219mm | 900mm | 3mm | Φ300*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 219mm | 1200mm | 3mm | Φ300*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 219mm | 900mm | 5mm | Φ300*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 219mm | 1200mm | 5mm | Φ300*8mm | 4*Φ16mm | Carbon steel/304SS/316SS | Flat/Dome/Bevel | |
| 168mm | 900mm | 3mm | Φ250*8mm | 4*Φ16mm | 304SS/316SS | Flat/Dome/Bevel | |
| 168mm | 1200mm | 3mm | Φ250*8mm | 4*Φ16mm | 304SS/316SS | Flat/Dome/Bevel | |
| 168mm | 900mm | 5mm | Φ250*8mm | 4*Φ16mm | 304SS/316SS | Flat/Dome/Bevel | |
| 168mm | 1200mm | 5mm | Φ250*8mm | 4*Φ16mm | 304SS/316SS | Flat/Dome/Bevel |
The standard carbon steel fixed bollards are manufactured using high-quality Q235 Steel to ensure superior strength and impact resistance.
For Carbon Steel bollards, the default finish options are hot-dip galvanized or E-coated combined with a durable powder coating for optimal outdoor rust prevention.
Stainless steel fixed bollards (available in 304SS and 316SS grades) feature a high-quality satin polished finish as standard.
Yes, we offer multiple top designs for related bollard models, including Flat, Dome, and Bevel head configurations to match your aesthetic and safety requirements.
Base plate sizes range from Φ170*8mm up to Φ300*8mm depending on the outer diameter of the bollard. Most models come standard with 4 mounting holes of Φ16mm for secure ground anchoring.
